Brand:winday
1. Main parts: 3 Extruders, Control Panel, Bubble forming section, Automatic Winder,Rewinder.
2. To produce 5 layers air bubble film (laminated layer + PE front layer + bubble layer + base layer + laminated layer);
3. The laminated layer can be aluminized foil, MPET foil, kraft paper, EPE foam, BOPP film etc.;
4. Each layer is under individually control, can have different thickness & material formulation and color;
5. Film width from 1,000mm to 3,000mm;Or Customized size.
6. Screw L/D ratio is 1:32, it adopts special mixing function and high plasticizing capacity design, with good plasticization, good mixing effect and high output;
7. The bubble forming cylinder adopts special internal circulation chilled water design to ensure perfect bubble forming effect under high speed operation.
|
Model |
WD100-5T |
WD120-5T |
WD160-5T |
WD200-5T |
WD250-5T |
WD300-5T |
|
Max width mm |
1000 |
1200 |
1600 |
2000 |
2500 |
3000 |
|
Screw diameter mm |
55/55/55 |
55/55/55 |
65/65/55 |
75/75/65 |
85/85/75 |
90/90/80 |
|
Main motor power kw |
15/15/15 |
15/15/15 |
22/22/15 |
30/30/22 |
37/37/30 |
37/37/30 |
|
Capacity Kg/hr |
65-135 |
85-140 |
100-180 |
160-230 |
180-270 |
200-290 |
|
Line speed M/hr |
800-1800 |
800-1800 |
800-1800 |
800-1500 |
800-1500 |
800-1500 |
|
Heating power kw |
83 |
83 |
95 |
112 |
143 |
150 |
|
Running power kw |
47 |
49 |
65 |
80 |
90 |
98 |
|
Total power kw |
137 |
141 |
177 |
232 |
282 |
302 |
|
Raw material |
LDPE/LLDPE/ Recycle material |
LDPE/LLDPE/ Recycle material |
LDPE/LLDPE/ Recycle material |
LDPE/LLDPE/ Recycle material |
LDPE/LLDPE/ Recycle material |
LDPE/LLDPE/ Recycle material |
|
Machine Weight kg |
7700 |
8500 |
9500 |
10700 |
12700 |
13300 |
