Brand:winday
The Wanday company's independent innovation product after years of research and development, this machine is specially used to produce double-side sealed bubble film envelope bags. This equipment is a fully automatic equipment for making composite bubble envelope bags. The materials that customers need to prepare: coated kraft paper, bubble film, and adhesive strips.
There are six models in total, which can automatically produce all kinds of bubble envelope bags that can be seen at home and abroad.
Kraft paper+bubble film; aluminum foil+bubble film; BOPP film+bubble film; PO film+bubble film; PE film+bubble film; The equipment makes a wide range of products and high degree of automation. It is an ideal equipment for making composite bubble envelope bags.
Features:
This machine is controlled by computer, imported servo motor for traction, constant tension of unwinding, photoelectric correction, convenient operation, counting of whole book, automatic stop when label is lost, automatic stop when lack of material, etc. The machine adopts advanced motion control technology, from sheet material unwinding to cutting and forming are controlled by PLC computer, servo motor fixed length, touch screen control, simple operation, stable operation, smooth and beautiful bags, strong and reliable bonding .
|
Suitable material |
kraft paper 80-110g/sqm (coated)+PE bubble film |
|
Max design speed |
80pcs/min(can make two at one time for small size) |
|
Max bag length |
550mm for one bag make 350mm for two bag one time |
|
Max bag width |
450mm |
|
Max reel width |
1400mm. |
|
Max reel diameter: |
Kraft paper ￠1200mm, PE bubble ￠1200mm |
|
Power supply |
3-phase 4-lines AC 380V 50HZ 25KW |
|
Machine Weight |
3800KG |
|
Overall dimension(L*W*H) |
16400*1750*2300mm |
